TTC 凌雪轴HI-FI磁轴轴体

销售价格$8.00正常价格 $11.50
尺寸
尺寸: 10件
库存，准备出货
Switch Spec

轴体类型: 霍尔磁轴
初始力: 32±6gf
总行程: 3.4±0.2mm
弹簧长度: 18mm
轴心材质: Pom
上盖材质: PC
出厂润滑: 有

取货地点： 160 Gibson Drive

通常在 24 小时内就绪
Description
Description

TTC 凌雪轴HI-FI磁轴轴体

TTC 首款镂空雪花工艺设计磁轴

TTC 凌雪轴磁轴轴体是 TTC 推出的线性磁轴方案，主打轻压力、顺滑手感和极具辨识度的外观设计。这颗轴采用 TTC 首款镂空雪花工艺设计，在保持性能表现的同时，也让整体视觉更轻盈、更有特色。

参数方面，这颗轴的初始压力为 32±6gf，总行程为 3.4±0.2mm，并支持自定义触发行程。磁通部分为 90±20Gs 初始磁通 和 480±50Gs 终点磁通（基于 1.6mm PCB），可以带来更细致的磁轴触发体验。

结构上，凌雪轴采用 18mm 长弹簧，并加入柔弹设计和防尘轴心结构，在按压顺滑度、回弹表现和日常稳定性上都有更完整的表现。同时，这颗轴还加入了通风散热设计，进一步提升整体结构辨识度。

材质方面，轴心使用 POM，上盖为 PC，底壳为 POM。官方标称寿命可达 1 亿次按压，是一颗兼顾性能、耐用性和外观设计的线性磁轴。

规格参数

  • 类型： 线性磁轴
  • 初始压力： 32±6gf
  • 初始磁通： 90±20Gs（PCB 1.6mm）
  • 终点磁通： 480±50Gs（PCB 1.6mm）
  • 触发行程： 支持自定义
  • 总行程： 3.4±0.2mm
  • 寿命： 1 亿次
  • 弹簧： 18mm 长弹簧
  • 设计： 柔弹设计 / 防尘轴心结构 / 通风散热设计 / 镂空雪花工艺
  • 轴心材质： POM
  • 上盖材质： PC
  • 底壳材质： POM
